Specification of Centrifugal Air Cooler
Characteristics:
1. Using specially designed centrifugal fan, with large airflow, far air supply distance, low noise, wide applicability, low energy consumption compared with similar products.
2. Different air discharge type (including top, down and side) can meet different installation requirements of various applications.
3. The casing is made of high strength weather ability polymers which is UV-proof, anti-aging, and resistant to deformation
4. Using high quality aluminum housing motor, with good heat dissipation, high protection grade, waterproof and moisture-proof
5. Using automatic control of water system and opean type water distributor, so water can flow smoothly and distributor is not easy to block
6. Using highly efficient cooling pads with large evaporation capacity, good cooling efficiency and easy cleaning
Function:
1. Automatically swinging diffuser
2. LCD full function
3. CE, BV, ETL certificate
4. High quality motor
Use place:
Public places such as industry, airport, train station, bus station, shopping mall, showroom, gymnasium, restaurant, school, conference hall, shop-floor, storage, canteen, office, recreation facilities, etc
FAQ:
Q1: Are you the trading company or manufacturer?
A1: Our company is evaporative air cooler global suppler that specializing manufacture in the air cooler (industry or home), exhaust fan and air cooler parts. We have profuse designs with series quality grade and expressly.
Q2: Can you offer me better price?
A2: Our price is very competitive because we are the designing, molding, injection, sales of one of manufacturers.
Q3: Can you make specific voltage and thickness of cooling pad, and use our own brand ?
A3: We can offer 110V-120V, 220V-240V, 380V-415V., frequency 50HZ-60HZ. Cooling pad always we use is 10mm, if you need 12mm, we also can make for you. For air cooler brand, we can OEM & ODM for you.
Q4: What is the payment term?
A4: Always is T/T(30/70), also the at sight L/C.
Q5: How long is your air cooler warranty?
A5: The warranty time for air cooler is 1 year. If the parts broken in 1 year, we all can offer you new parts in next order.
Q6: How long is the delivery time?
A6: Generally it is within 7-10 days after the deposit. but also depend on the order quantity. we promise offer in 1 month.
| Model | CY-18AC/DC/SC | CY-18AC1/DC1/SC1 | CY-30TC/DC/SC |
| Air discharge | Top/Down/Side | Top/Down/Side | Top/Down/Side |
| Power | 0.75Kw | 1.1Kw | 1.1Kw |
| Air flow(m³/h) | 12000 | 15000 | 20000 |
| Fan type | Centrifugal | Centrifugal | Centrifugal |
| Voltage | 3 phase 380/415V | 3 phase 220V | 3 phase 220V |
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz |
| Control system | Frequency inverter system / Single speed controller | ||
| Size | 1.08*1.08*1.18m | 1.08*1.08*1.18m | 1.3*1.3*1.18m |
| Air pressure | 235Pa | 250Pa | 300Pa |
| Cooling area | 80-100m² | 120-150m² | 250-300m² |
| Noise | ≤70DB | ≤70DB | ≤70DB |
| Water tank | 30L | 30L | 30L |
| Water consumption | 10-15L/h | 10-15L/h | 10-15L/h |
| Weight | 100Kg | 100Kg | 120Kg |
| Air outlet size | 670*670mm | 670*670mm | 800*800mm |
